High speed optional A3 Flatbed scanner perfect for scanning bound and fragile media.
Enjoy a seamless dual scanning operation with Canon Flatbed Scanner Unit 201 and our imageFORMULA range providing greater versatility and precision when scanning books, journals and fragile documents.
Canon’s Flatbed Scanner Unit 201 offers high speed A3 scanning of up to 3.5sec at 200dpi. It’s quick to get going thanks to Canon’s LED light source technology, which means no warm up time is needed. Once connected to a DR-scanner you can take advantage of high speed batch scanning alongside fast A3 flatbed scanning. That’s vital time saving and increased productivity in one.
The A3 Flatbed Scanner Unit 201 is ideal for scanning a wide range of media including books, ledgers and fragile documents – perfect for Government offices, libraries, the construction industry and general office departments.
The seamless connectivity between Canon imageFORMULA scanners and the Flatbed Scanner Unit 201 enables greater scanning control when optimising both ADF and flatbed capture in a single operation. Scan in multiple formats into a single document file and send directly to various output destinations including email, folders and popular data management applications with ease. Intelligent communication between scanners means the A3 Flatbed will start scanning if it detects there is no paper in the document feeder of the DR-scanner when connected.
The Flatbed Scanner Unit 201 incorporates a range of advanced image processing features, including the smart ambient light cancelling mode that enables users to scan with the lid open and still deliver high-quality images. This is a valuable productivity-booster when needing to scan large volumes at speed. Furthermore, it inherits the image processing features of the DR-scanner such as auto page size detection, deskew and MultiStream – helping you to maintain the consistency of high quality scans every time.
The Flatbed Scanner Unit 201 features a slim, elegant and compact design, while its footprint is only slightly larger than an A3 piece of paper. So it’s equally well suited to a permanent place on the desktop or easy storage when not in use.
|Type||Universal A3 Flatbed Scanner Option|
|Scanning sensor unit||CCD Sensor|
|Light source||LED RGB|
|Interface||High speed USB 2.0|
|Dimensions (WxDxH)||Tray Closed: 571mm (W) x 436 (D) x 96 (H) mm|
|Power requirements||AC100 - 240V (50/60Hz)|
|Power consumption||Scanning 21W or less, Sleep Mode 3.1W or less, Power Turned Off less that 0.3W|
|Operating environment||10 - 32.5°C (50 - 90.5°F), Humidity: 20 - 80% RH|
|Environmental compliance||RoHS and ENERGY STAR|
|Black and White||A4: 3.0 seconds A3: 3.5 seconds|
|Colour||A4: 3.5 seconds A3: 4.5 seconds|
|Output resolution||100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi|
|Output mode||Black and White, Error Diffusion, Advanced Text Enhancement II, 8-bit Greyscale (256-level), 24-bit Colour, Auto Colour Detection|
|Width||Up to 297.4mm|
|Length||Up to 431.8mm|
|-||Automatic Page Size Detection, Deskew, Ambient Light Cancelling Mode, Scan Area Setting, Scanning side, Contrast Arrangment Automatic Resolution Setting. |
(Inherits image processing function from connected DR-series scanners)
