IMAGE SENSOR
Type
1/2.3 type CCD
Effective Pixels
Approx. 20.0M¹
Effective / Total Pixels
Approx. 20.5M
Colour Filter Type
Primary Colour
IMAGE PROCESSOR
Type
DIGIC 4+ with iSAPS technology
LENS
Focal Length
4.3 – 43.0 mm (35 mm equivalent: 24 – 240 mm)
Zoom
Optical 10x
ZoomPlus 20x
Digital approx. 4x
Combined approx. 40x¹
Maximum f/number
f/3.0 – f/6.9
Construction
9 elements in 7 groups
(1 double-sided aspherical lens)
Image Stabilisation
Yes (lens shift-type), approx. 2.5-stop¹. Intelligent IS plus Enhanced Dynamic IS
FOCUSING
Type
TTL
AF System/ Points
AiAF (Face Detection / 9-point), 1-point AF (fixed to centre)
AF Modes
Single, Continuous (Auto mode only), Servo AF/AE, Tracking AF¹
AF Assist Beam
Yes
Closest Focusing Distance
1 cm (W) from front of lens in Macro
EXPOSURE CONTROL
Metering modes
Evaluative (linked to Face Detection AF frame), Centre-weighted average, Spot (centre)
Exposure Compensation
+/- 2 EV in 1/3 stop increments.
Enhanced i-Contrast for automatic dynamic range correction
ISO sensitivity
AUTO, 100, 200, 400, 800, 1600
SHUTTER
Speed
1 – 1/2000 s (factory default)
15 – 1/2000 s (total range – varies by shooting mode)
WHITE BALANCE
Type
TTL
Settings
Auto (including Face Detection WB), Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Custom
COLOUR MATRIX
Type
sRGB
LCD MONITOR
Monitor
6.8 cm (2.7") LCD (TFT), approx. 230,000 dots
Coverage
Approx. 100%
Brightness
Adjustable to one of five levels. Quick-bright LCD
FLASH
Modes
Auto, Manual Flash On / Off, Slow Synchro
Slow Sync Speed
Yes. Fastest speed 1/2000 s
Red-Eye Reduction
Yes
Flash Exposure Compensation
Face Detection FE, Smart Flash Exposure
Built-in Flash Range
50 cm – 4.0 m (W) / 1.0 – 2.0 m (T)
External Flash
Canon High Power Flash HF-DC2
SHOOTING
Modes
Smart Auto (32 scenes detected), P, Portrait, FaceSelf-Timer, Low Light (5.0 MP), Fish-eye Effect, Miniature Effect, Toy Camera Effect, Monochrome, Super Vivid, Poster Effect, Fireworks, Long Shutter
Modes in Movie
Smart Auto (21 scenes detected), P, Portrait, Miniature Effect, Monochrome, Super Vivid, Poster Effect, Fireworks
Drive modes
Single, Continuous, Self-Timer
Continuous Shooting
Approx. 0.8 shots/s
Low Light Mode (5.0 MP): Approx. 2.2 shots/s
(all speeds are until memory card becomes full)¹²
RECORDING PIXELS / COMPRESSION
Image Size
4:3 - (L) 5152 x 3864, (M1) 3648 x 2736, (M2) 2048 x 1536, (S) 640 x 480, (W) 5152 x 2896
Resize option available in playback
Compression
Fine
Movies
(HD) 1280 x 720, 25 fps, (L) 640 x 480, 29.97 fps
Miniature Effect (HD) 5 fps, 2.5 fps, 1.25 fps
Miniature Effect (L) 6 fps, 3 fps, 1.5 fps
Movie Length
(HD) Up to 4 GB or 29 min 59 s¹
(L) up to 4 GB or 1 hour²
FILE TYPES
Still Image Type
JPEG compression, (Exif 2.3 [Exif Print] compliant) / Design rule for Camera File system, Digital Print Order Format [DPOF] Version 1.1 compliant
Movies
MP4 [Video: MPEG4-AVC / H.264, Audio: MPEG4 AAC-LC (monaural)]
DIRECT PRINT
Canon Printers
Canon SELPHY Compact Photo Printers and Canon Inkjet Printers supporting PictBridge
PictBridge
Yes (via USB or Wireless LAN)
OTHER FEATURES
GPS
GPS via mobile (via Canon Camera Connect app with compatible smart devices)
Red-Eye Correction
Yes
Intelligent Orientation Sensor
Yes, with Auto Rotate
Histogram
Yes, during playback
Playback zoom
Approx. 2x – 10x
Self Timer
Approx. 2, 10 s or Custom
Menu Languages
English, German, French, Dutch, Danish, Finnish, Italian, Greek, Norwegian, Portuguese, Russian, Swedish, Spanish, Ukrainian, Polish, Czech, Hungarian, Turkish, Simplified Chinese, Chinese (traditional), Japanese, Korean, Thai, Arabic, Romanian, Farsi, Hindi, Malay, Indonesian, Vietnamese, Hebrew
INTERFACE
Computer
Hi-Speed USB composite connector (Mini-B compatible)
Other
A/V output, composite connector (PAL/NTSC)
Computer/Other
Wi-Fi (IEEE802.11b/g/n), (2.4 GHz only), with Dynamic NFC support ¹
MEMORY CARD
Type
SD, SDHC, SDXC
SUPPORTED OPERATING SYSTEM
PC & Macintosh
Windows 10 / 8.1 / 8 / 7 SP1¹
Mac OS X 10.9 / 10.10 / 10.11
For Wi-Fi connection to a PC:
Windows 10 / 8.1 / 8 / 7 SP1
Mac OS X 10.9 / 10.10
For Image Transfer Utility:
Windows 10 / 8.1 / 8 / 7 SP1
Mac OS X 10.9 / 10.10 / 10.11
SOFTWARE
Other
CameraWindow DC
Map Utility
Image Transfer Utility
Camera Connect app available on iOS and Android devices
POWER SOURCE
Batteries
Rechargeable Li-ion Battery NB-11L / NB-11LH (NB-11L battery and charger supplied)
Battery life
Approx. 190 shots
Eco Mode: Approx. 245 shots
Playback Mode: Approx. 240 min
ACCESSORIES
Cases / Straps
Soft Case DCC-1320
Soft Case DCC-1370
Flash
Canon High Power Flash HF-DC2
Power Supply & Battery Chargers
Battery Charger CB-2LFE
Rechargeable Li-ion Battery NB-11LH
Other
Canon AV Cable AVC-DC400
Interface cable IFC-400PCU
PHYSICAL SPECIFICATIONS
Operating Environment
0 – 40 °C, 10 – 90% humidity
Dimensions (WxHxD)
95.3 x 56.8 x 23.6 mm
Weight
Approx. 138 g (including battery and memory card)
Disclaimer
All data is based on Canon standard testing methods (according to CIPA Standards) except where indicated.
Subject to change without notice.
All data is based on Canon standard testing methods (according to CIPA Standards) except where indicated.
Subject to change without notice.
Footnote
¹ Image processing may cause a decrease in the number of pixels.
¹ Depending on the image size selected.
¹ Values at maximum optical focal length. Cameras whose focal length exceeds 350 mm (35 mm equivalent) are measured at 350 mm.
¹ Some settings limit availability.
¹ Under conditions where the flash does not fire.
² Depending on memory card speed / capacity / compression setting.
¹ The following Speed Class memory cards are required for maximum record time: (HD) 1280 x 720 Speed Class 4 or above. (Full HD) 1920 x 1080 Speed Class 6 or above. (iFrame) 1280 x 720 Speed Class 6 or above.
² Depending on memory card speed / capacity / compression setting.
¹ Wi-Fi use may be restricted in certain countries or regions. Wi-Fi support varies by device and region. For more information visit www.canon-europe.com/wirelesscompacts
¹ Software applications compatible with Windows 10 in Windows 10 Desktop Mode only
¹ Image processing may cause a decrease in the number of pixels.
¹ Depending on the image size selected.
¹ Values at maximum optical focal length. Cameras whose focal length exceeds 350 mm (35 mm equivalent) are measured at 350 mm.
¹ Some settings limit availability.
¹ Under conditions where the flash does not fire.
² Depending on memory card speed / capacity / compression setting.
¹ The following Speed Class memory cards are required for maximum record time: (HD) 1280 x 720 Speed Class 4 or above. (Full HD) 1920 x 1080 Speed Class 6 or above. (iFrame) 1280 x 720 Speed Class 6 or above.
² Depending on memory card speed / capacity / compression setting.
¹ Wi-Fi use may be restricted in certain countries or regions. Wi-Fi support varies by device and region. For more information visit www.canon-europe.com/wirelesscompacts
¹ Software applications compatible with Windows 10 in Windows 10 Desktop Mode only
